Fig
No. |
Index
No. |
S
t
o
c
k
e
d
|
Group - Fixed Equipment |
Units
per
assembly |
Blue
prints |
| Major Assembly - Wing Bomb Installation |
| Part number |
Description |
| 125 |
10 |
|
75-70-441 |
Plate |
1 |
 |
| 125 |
12 |
|
AN392-13 |
Pin |
3 |
|
| 125 |
13 |
|
AN960-4 |
Washer |
3 |
|
| 125 |
5 |
|
AN380C2-2 |
Pin - Cotter |
3 |
|
| 125 |
40 |
|
87-681-1031-3-57 |
Cable Assembly - Panel release LH |
1 |
|
| 125 |
41 |
|
87-681-1031-8-56.20 |
Cable |
1 |
|
| 125 |
16 |
|
87-681-1063 |
Clevis |
1 |
|
| 125 |
39 |
|
AN668-2 |
Terminal - Eye and cable |
1 |
|
| 125 |
52 |
|
87-681-1031-3-67 |
Cable Assembly - Panel release RH |
1 |
|
| 125 |
53 |
|
87-681-1031-8-66.20 |
Cable |
1 |
|
| 125 |
16 |
|
87-681-1063 |
Clevis |
1 |
|
| 125 |
39 |
|
AN668-2 |
Terminal - Eye and cable |
1 |
|
| 125 |
54 |
|
87-681-1033L |
Support Assembly - Wing bomb |
1 |
, |
| 125 |
55 |
|
87-681-1033R |
Support Assembly - Wing bomb |
1 |
, |
| 125 |
56 |
|
87-681-1031-90 |
Cable Assembly - Arming |
1 |
|
| 125 |
57 |
|
87-681-1031-6-88.10 |
Cable |
1 |
|
| 125 |
16 |
|
87-681-1063 |
Clevis |
1 |
|
| 125 |
58 |
|
58766-1 1-4 |
Spring |
1 |
|
| 125 |
59 |
|
87-681-1031-1-60 |
Cable Assembly - Release |
1 |
|
| 125 |
60 |
|
87-681-1031 C 58.10 |
Cable |
1 |
|
| 125 |
16 |
|
87-681-1063 |
Clevis |
1 |
|
| 125 |
61 |
|
PC2891 |
Pin (Aero Supply) |
1 |
|
| 125 |
62 |
|
87-681-1064L |
Bracket Assembly - Pulley LH |
1 |
|
| 125 |
63 |
|
87-681-1064R |
Bracket Assembly - Pulley RH |
1 |
|
| 125 |
64 |
|
87-681-1064-1 |
Bracket Assembly |
1 |
|
| 125 |
65 |
|
1025D1.38-.312 |
Spacer |
4 |
|
| 125 |
26 |
|
AN210-1A |
Pulley |
4 |
|
| 125 |
66 |
|
AN3-6 |
Bolt |
2 |
|
| 125 |
67 |
|
AN3-15 |
Bolt |
1 |
|
| 125 |
4 |
|
AN960-10 |
Washer |
3 |
|
| 125 |
45 |
|
AN364-1032 |
Nut |
3 |
|
| 125 |
68 |
|
AN3-4 |
Bolt |
2 |
|
| 125 |
9 |
|
AN365-1032 |
Nut |
2 |
|
| 125 |
4 |
|
AN960-10 |
Washer |
2 |
|
| 125 |
69 |
|
87-681-1028 |
Bracket |
1 |
|
| 125 |
26 |
|
AN210-1A |
Pulley |
1 |
|
| 125 |
66 |
|
AN3-6 |
Bolt |
1 |
|
| 125 |
4 |
|
AN960-10 |
Washer |
1 |
|
| 125 |
9 |
|
AN365-1032 |
Nut |
1 |
|
| 125 |
68 |
|
AN3-4 |
Bolt |
2 |
|
| 125 |
9 |
|
AN365-1032 |
Nut |
2 |
|
| 125 |
4 |
|
AN960-10 |
Washer |
2 |
|
| 125 |
70 |
|
87-030-1017L |
Support Assembly LH |
1 |
|
| 125 |
71 |
|
87-030-1017R |
Support Assembly RH |
1 |
|
| 125 |
72 |
|
87-45-533-10 |
Shackle Assembly |
1 |
|
| 125 |
73 |
|
43D10157 |
Shackle (Type B-10) (GFE) (See T.O. 11-5-66) |
1 |
|
| 125 |
74 |
|
87-45-533-5 |
Extesion |
1 |
|
| 125 |
75 |
|
AN6-13 |
Bolt |
2 |
|
| 125 |
76 |
|
AN960-616 |
Washer |
4 |
|
| 125 |
76 |
|
AN960-616 |
Washer |
4 |
|
| 125 |
77 |
|
AN310-6 |
Nut |
2 |
|
| 125 |
78 |
|
AN380-3-3 |
Pin - Cotter |
2 |
|
| 125 |
79 |
|
87-681-1057-1 |
Filler |
8 |
|
| 125 |
80 |
|
AN502-10-12 |
Screw |
8 |
|
| 125 |
81 |
|
87-681-1057-2 |
Filler |
4 |
|
| 125 |
82 |
|
AN502-416-12 |
Screw |
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
