Fig
No. |
Index
No. |
S
t
o
c
k
e
d
|
Group - Fixed Equipment |
Units
per
assembly |
Blue
prints |
| Major Assembly - Airplane Electrical Installatoin - Power Plant and Fuselage Electrical Installation |
| Part number |
Description |
| 86 |
28 |
|
87-550-1020-40 |
Box Installation - Winterization junction |
1 |
|
| 86 |
29 |
|
87-550-1020-60 |
Box Installation - Winterization junction |
1 |
|
| 86 |
30 |
|
87-550-1020-70 |
Box Installation - Winterization junction (See Figure 88) |
1 |
|
| 86 |
31 |
|
87-66-082-6 |
Box Installation - Retracting motor switch |
1 |
|
| 86 |
32 |
|
87-552-1020 |
Box Installation - Battery junction |
1 |
 , |
| 86 |
33 |
|
87-552-1020-10 |
Box Installation - Battery junction |
1 |
|
| 86 |
34 |
|
87-552-1020-20 |
Box Installation - Battery junction |
1 |
|
| 86 |
35 |
|
87-552-1020-30 |
Box Installation - Battery junction |
1 |
|
| 86 |
36 |
|
87-552-1410 |
Box Installation - Hydraulic pump and radio |
1 |
|
| 86 |
37 |
|
87-552-1516 |
Switch Assembly - Aileron trim tab |
1 |
|
| 86 |
38 |
|
8TJ13LAH |
Transmitter - Fuel quantity (General Electric) |
1 |
|
| 86 |
39 |
|
87-552-1074 |
Box Assembly - Recognition light control |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
