Fig
No. |
Index
No. |
S
t
o
c
k
e
d
|
Group - Wing |
Units
per
assembly |
Blue
prints |
| Major Assembly - Wing Erection - Landing Gear Support and Gun Heater Installation |
| Part number |
Description |
| 6 |
21 |
|
87-81-515-1L |
Heater Installation - Wing gun LH |
1 |
|
| 6 |
21 |
|
87-81-515-1R |
Heater Installation - Wing gun RH |
1 |
|
| 6 |
23 |
|
87-81-518 |
Adapter |
1 |
 |
| 6 |
24 |
|
87-81-528 |
Tube |
1 |
|
| 6 |
25 |
|
FBA58 |
Clamp (Wittek) |
2 |
|
| 6 |
26 |
|
87-81-925 |
Grommet |
2 |
|
| 6 |
27 |
|
87-81-540 |
Clamp |
1 |
|
| 6 |
28 |
|
AN3-4A |
Bolt |
2 |
|
| 6 |
29 |
|
AN365-1032 |
Nut |
2 |
|
| 6 |
30 |
|
1042DD44 |
Clamp |
1 |
|
| 6 |
31 |
|
AN530-10-10 |
Screw |
1 |
|
| 6 |
32 |
|
AN365-1032 |
Nut |
1 |
|
| 6 |
29 |
|
AN365-1032 |
Nut |
1 |
|
| 6 |
33 |
|
87-81-533L |
Adapter LH |
1 |
|
| 6 |
34 |
|
87-81-533R |
Adapter RH |
1 |
|
| 6 |
34 |
|
FBA20 |
Clamp (Wittek) |
2 |
|
| 6 |
35 |
|
87-81-530-1 1-2-27 |
Tube |
1 |
|
| 6 |
36 |
|
87-81-530-1 1-2-14 |
Tube |
1 |
|
| 6 |
37 |
|
1042DD30 |
Clamp |
4 |
|
| 6 |
38 |
|
AN515-8-12 |
Screw |
4 |
|
| 6 |
39 |
|
AN365-832 |
Nut |
4 |
|
| 6 |
40 |
|
87-81-717 |
Plug |
1 |
|
| 6 |
41 |
|
FBA24 |
Clamp (Wittek) |
1 |
|
| 6 |
42 |
|
87-03-916L |
Bulkhead LH |
1 |
|
| 6 |
42 |
|
87-03-916R |
Bulkhead RH |
1 |
|
| 6 |
43 |
|
AN3-6A |
Bolt |
13 |
|
| 6 |
44 |
|
AN960-10 |
Washer |
13 |
|
| 6 |
29 |
|
AN365-1032 |
Nut |
13 |
|
| 6 |
45 |
|
AN3-7A |
Bolt |
1 |
|
| 6 |
44 |
|
AN960-10 |
Washer |
1 |
|
| 6 |
29 |
|
AN365-1032 |
Nut |
1 |
|
| 6 |
46 |
|
AN3-12A |
Bolt |
1 |
|
| 6 |
44 |
|
AN960-10 |
Washer |
1 |
|
| 6 |
29 |
|
AN365-1032 |
Nut |
1 |
|
| 6 |
47 |
|
AN3-5A |
Bolt |
12 |
|
| 6 |
44 |
|
AN960-10 |
Washer |
12 |
|
| 6 |
29 |
|
AN365-1032 |
Nut |
12 |
|
| 6 |
45 |
|
AN3-7A |
Bolt |
1 |
|
| 6 |
44 |
|
AN960-10 |
Washer |
1 |
|
| 6 |
29 |
|
AN365-1032 |
Nut |
1 |
|
| 6 |
48 |
|
AN3-10A |
Bolt |
1 |
|
| 6 |
44 |
|
AN960-10 |
Washer |
1 |
|
|
|
